BSX 5-1-OJ Self-Regulating Heating Cable
Product Info
TubeTrace, with “cut-to-length” BSX self-regulating heat tracing, is designed to provide freeze protection or temperature maintenance for tubing where no “steam out” of the tubing is possible. BSX withstands temperature exposures of 85°C (185°F). Self-regulating BSX heat tracing
Varies in response to the surrounding conditions along the entire length of a circuit.
Lower risk of overheating the tube or product.
Installed cost is lower because “cut-to-length” BSX makes end connections easy with minimal waste
Features:
- Self-regulating
- “Cut-to-length”
- Hazardous area approvals
Thermon BSX 5-1-OJ | Self-Regulating Heating Cable | 110-120 or 208-277 Vac Supply Voltages | 40°F to 150°F (5°C to 65°C) Tube Temperature Range
Thermon reserves the right to ship within a
variance of – 0/+ 15% of the length ordered for each
specific catalog number. Quantity may change and
Invoices will be for the actual length shipped.
Item Specifications
-
3, 5, 8, 10 w/ft @ 50°F (10, 16, 26, 33 w/m @ 10°C)
-
185°F (85°C)
-
110-120 or 208-277 Vac
-
T6 185°F (85°C)
-
40°F to 150°F (5°C to 65°C)
